Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.
| Material | Polypropylene |
| Material sealing gasket | TPE |
| Temp. range min | -30 °C |
| Temp. range max | 100 °C |
| Temperatures during install. | -5 °C - 60 °C |
| Protection class | IP66 / IP67 |
| Glow wire test | 960 °C |
| Voltage | 400 V |
| Rated cross section | 4 mm² |
| Fixing | 4 internal openings |
| Ø cable diameter min | 3 mm |
| Ø cable diameter max | 12 mm |
| External dimensions LxWxH | 85 x 85 x 51 mm |
| Type of cable gland | M 20 x 1,5 |
| Using for cable gland |
 |
| Product Color | RAL 9005 |
| WISKA-Order no. | 10111023 |
| Type | COMBI MAR 308 BK |
| Packing unit | 5 |
| ETIM-Classification | EC002600 |
| EAN number | 4007686269956 |
| Tariff number | 39269097 |
| Remarks: IP66: using the membrane entry IP67: using the threaded entry together with ESKV cable gland Equipment: - 8 M20 threaded membrane entries - 4 captive cover screws Fixing: With 4 internal openings outside of the sealing area |
|
DNV COMBI MAR C-EN
